19" Pioneer Studio Teleprompter

The Autocue 19" Pioneer Studio Teleprompter is a great choice for broadcast style studios that aren?t using box lenses (Autocue has a 19" Studio Box Lens Teleprompter if you are). Its adjustable mounting kit makes sure that setup goes smoothly with simple tuning of the hood height so that the lens is always in the middle of the glass, and a counterweight included to centre the load of the prompter on the tripod or pedestal.

Pioneer Series packages include Autocue?s highest spec monitors with a brightness that will out-perform any lighting situation to keep your presenter on-script. Like all Autocue monitors they have a strong metal housing ready to take years of hard work. With HD-SDI, CVBS, VGA, and HDMI inputs to choose from you can be sure the prompter will integrate whether you have a single PC or a full broadcast facility.

The Pioneer Studio Teleprompter comes with Autocue?s largest hood to ensure there?s no chance of unwanted vignetting, at even the widest angle. The hood is made of a lightweight composite and holds Autocue 70:30 beamsplitter glass that clearly displays the text to the presenter while keeping it invisible to the camera. If you need to show even more info to your presenter, Autocue offers accessories for tally, time and talent feedback.

Technical specifications

Aspect Ratio: 4:3

Aux. Output: 12V DC, 3A max

Brightness: 1500Nits

Camera Base To Lens Centre Height Supported: 50 mm to 14 cm / 1.97 in to 5.51 in

Connectivity: 3G/HD/SD-SDI (with looped output), CVBS (with looped output), HDMI, VGA

Contrast: 1000:1

Counterweight: 5 kg / 11.02 lb

Counterweight Mounting Rods: 2x 19mm dia.

Hood: Large (wide angle) composite hood with collapsible fabric lens seal

Image Flip: Horizontal & vertical

Input Voltage: 12V DC

Inputs: 3G/HD/SD-SDI, CVBS, HDMI, VGA

Monitor Dimensions: 42 cm x 35.6 cm x 57 mm / 16.54 in x 14.02 in x 2.24 in

Monitor Mounting: VESA100 with additional 3-8"-16 camera support fixings

Monitor Size: 19"

Monitor Weight: 4.4 kg / 9.7 lb

Power Consumption: 35W max

Power Supply: 110-240V AC 50/60Hz input, 12V DC, 5A max. output

Rail Fixings: 3/8"-16, with optional 1/4"-20 inserts

Resolution: 1280x1024

System Dimensions: 67.5 cm x 45.5 cm x 76.5 cm / 26.57 in x 17.91 in x 30.12 in

System Weight: 11.9 kg (excluding counterweight) / 26.23 lb (excluding counterweight)

Warranty: 2 Years

In the box

• Monitor

• PSU

• Mounting rail with bracket set

• Camera carriage

• Monitor spine

• Large hood

• Beamsplitter glass

• 19mm rod set

• 5kg counterweight

• HDMI cable, 10m

• UK/EU or US IEC power cable
