Duo C198P Battery 14.5V 193 Wh 2xD-Tap 1x USB PD

The DUO-C198P is the ideal compact battery solution for digital cinema cameras and camera stabilizer systems where long runtimes are required. With its ultra-robust 193Wh capacity and compact 2.4lb design, the DUO-C198P can provide mobile power to cine-style cameras such as the ARRI ALEXA Mini and RED Weapon effortlessly for extended periods at a time. The DUO-C198P also includes two on-battery D-Taps and USB-C outputs to power accessories such as monitors, lights, wireless receivers, tablets, phones and more!

Key Features.

193Wh capacity

The worlds most compact 193Wh Lithium Ion battery (2.4 lbs in weight)

Capable of handling up to 14A loads ‡

(1) 80W D-Tap Advanced Output (unregulated) – D-Tap Output with the added ability to charge battery using low-cost D-Tap Charger (VL-DT1)

(1) 80W D-Tap Output (unregulated)

(1) USB-C PD max. input/output 60W (5.0V/3A, 9.0V/3A, 12V/3A, 15V/3A, 20V/3A)(auto shut off after 30 minutes of inactivity)

Battery can be charged from USB-C using affordable charger (UC-PD1)

5 Power Indicator LEDs (displaying 10% increments)

Battery circuit protection ensures the DUO-C198P is fully protected against common causes of battery misuse, guarding against over charge, over discharge, over current and exposure to high temperatures

The highest grade Lithium Ion cells are used to ensure the DUO-C198P is one of the most reliable batteries on the market

11V auto cut-off prevents over-discharging (while load is applied)

Fully compatible with all ENDURA V-Mount Battery chargers and accessories

Environmentally friendly and recyclable

Antiviral and antimicrobial body for peace of mind

Technical specifications

Battery Type: 1x V-Mount

Battery Capacity: 9900 mAh / 193 Wh

Output Voltage: 14.5 VDC

Battery Chemistry: Lithium-Ion

Power I/O

1x D-Tap/P-Tap Female Input/Output

      Input: 80 W Maximum

1x D-Tap/P-Tap Female Output

      Output: 80 W Maximum

1x USB-C Female Input/Output

      Input: 60 W Maximum

Accessory Mounting Thread: No

Indicator: Status Light

Dimensions: 5.75 x 3.74 x 2.32" / 14.61 x 9.5 x 5.89 cm

Weight: 2.42 lb / 1.1 kg

Operating Conditions: 32 to 104°F / 0 to 40°C

Storage Conditions: -4 to 122°F / -20 to 50°C

Package Weight: 2.68 lb

Box Dimensions (LxWxH): 7.4 x 4.5 x 3.1"

Included items

IDX System Technology DUO-C198P 193Wh High-Load Li-Ion V-Mount Battery

Limited 2-Year Manufacturer Warranty
