SWIT PB-S146S 146Wh Multi-sockets Digital Battery, V-Mount

Square shape design for Cine-cameras
PB-S series camera batteries are compact designed, shorter than normal V/Gold mount batteries, and match perfectly with most of the Cine-cameras.

Key Features

Square shape design for Cine-cameras

146Wh, 10.1Ah larger capacity

At least 200W, 16A constant high load

2x D-tap output sockets (120W/10A in total)

1x USB 5V/2A power output sockets

OLED display accurate remaining run time

Display power info in both SONY & RED

Multiple circuit protections

Technical specifications

Nominal voltage: 14.4V
Capacity: 146Wh, 10.1Ah

Max output

In total: 150W

Electrodes: 150W,12A

USB:10W, 5V/2A

D-tap: 100W / 10A

Charging input: 16.8V 3A (Max)
Charging Temperature: 0 ~ 40°C
Discharging Temperature: -20°C ~ 50°C（Capacity and Max Load may decrease when operating below 0°）
Dimension: 121×95×59mm
Net weight: Net 0.878kg; With package0.9kg
Max charging current: 5A
D-TAP socket number: 2
USB socket number: 1
