SWIT PB-S98S 98Wh Multi-Sockets Digital Battery, V-Mount

Square shape design for Cine-cameras
PB-S series camera batteries are compact designed, shorter than normal V/Gold mount batteries, and match perfectly with most of the Cine-cameras.

Key Features

Square shape design for Cine-cameras

Max 150W, 12A load

2x D-tap output sockets (120W/10A in total)

1x USB 5V/2A power output sockets

OLED display accurate remaining run time

Display power info in both SONY & RED

Multiple circuit protections

Technical specifications

Model: PB-S290S Nominal voltage: 14.4V
Capacity: 98Wh,6.8Ah

Max output

In total: 150W

Electrodes: 150W,12A

USB:10W, 5V/2A

D-tap: 120W / 10A

Charging input: 16.8V 3A (Max)
Charging Temperature: 0 ~ 40°C
Discharging Temperature: -20°C ~ 50°C（Capacity and Max Load may decrease when operating below 0°）
Dimension: 121×95×59mm
Net weight: Net 0.809kg; With package0.85kg
Max charging current: 3A
D-TAP socket number: 2
USB socket number: 1
