Aputure Storm 1200x

The STORM 1200x uses an innovative new BLAIR light engine (Blue/Lime/Amber/Indigo/Red) to produce excellent full white spectrum across a wide CCT range with great fine-tune adjustability of +/- Green as well as other colors. Compared to traditional bicolor technology, the result is better quality white light and because all the emitters are contributing, a brighter white light as well. The ProLock Locking Bowens Mount is a secure clamp which allows the use of popular Bowens modifiers. The STORM 1200x also offers superior dimming capabilities and greater weather protection that competing products.

With our new breakthrough proprietary BLAIR chipset, the STORM 1200x delivers exceptional brightness and color accuracy. The STORM 1200x offers a hefty 22,500 lux @3m at 5,600K with its included hyper reflector while maintaining a SSI score of 87 at both 3,200K and 5,600K.The inclusion of an indigo diode in this chipset enhances the colors of fluorescing materials, resulting in an image that is more accurate to daylight and black body light sources. Featuring a CCT range of 2,500K-10,000K and advanced white-point control with green-magenta color correction (±G 100% full ASC MITC range), this fixture offers the versatility and critical color accuracy that professionals call for on set.

The STORM 1200x features the ProLock Locking Bowens Mount, a more secure clamping design for attaching modifiers. Bowens accessories are held rigidly in place and precision optics light fresnels and Spotlight projectors are precisely aligned with the light engine. Designed with higher stability, durability, and optimization
for optical precision modifiers, the ProLock Mount is compatible with three new reflectors (15degr., 30degr., 45degr.) and standard Bowens mount accessories.

Equipped with advanced dimming technology, the STORM 1200x ensures flicker-free, color-accurate operation during shooting even at its lowest output level of
With a rugged IP65 dust and weather resistant rating, the STORM 1200x is capable of withstanding even the most demanding filming environments in inclement weather without any impact to performance or reliability.

Technical Specifications

LED Chipset: BLAIR

CCT: 2,500K – 10,000K

Green-Magenta Adjustment Range: ±G 100% (Full ASC MITC Range)

CRI: ≥95 (3,000K)

TLCI: ≥95 (3,200K)

CQS: ≥94

SSI (Tungsten): 87

SSI (D56): 87

TM-30 RF (Average): 95

TM-30 RG (Average): 100

Max Power Consumption: 1550W

Max Power Output: 1200W

Weather Resistance Rating: IP65

Native Beam Angle: 67º

Included Reflector Beam Angle: 45°

Operating Voltage: 100V ~ 240V / 50-60 Hz

Operating Temperature: -20°C ~ 45°C / -4°F ~ 113°F

Storage Temperature: -40°C ~ 80°C / -40°F ~ 176°F

Control Methods

Data Ports: 1x 5-Pin DMX In, 1x 5-Pin DMX Out, 2x LAN

Control Methods: On-board, Sidus Link App, Sidus Link Pro App, DMX/RDM, CRMX, sACN & Art-Net, Sidus Link Pro Auto-Patching and Auto-Configuration

Firmware Upgradeable: Sidus Link, Sidus Link Pro, USB Drive

Wireless Range Sidus Bluetooth: ≤100m / ≤262.5ft

Wireless Range CRMX (TimoTwo): ≤100m / ≤262.5ft

Lamp Head Fan Noise Levels

Smart Mode: 52 dBA

High Mode: 43 dBA

Medium Mode: 34.4 dBA

Low Mode: 31 dBA

Silent Mode: 0 dBA

Max Control Box Noise Level All Modes: 28.5 dBA

Dimensions

Lamp Head (Without Yoke): 33.4 x 33.6 x 25.0cm 13.2 x 13.2 x 9.8in

Lamp Head (With Yoke): 33.4 x 33.6 x 55.7cm 13.2 x 13.2 x 21.9in

Control Box: 13.6 x 18.9 x 34.4cm 5.4 x 7.4 x 33.2in

Rolling Soft Case: 67.0 x 43.5 x 45.0 cm / 26.4 x 17.1 x 17.7 in

Weight

Lamp Head with Yoke: 9.50kg / 20.94lbs

Control Box: 5.92kg / 13.05lbs

Head Cable: 1.81kg / 3.99lbs

AC Power Cable: 0.65kg / 1.43lbs

Rolling Soft Case (Fully Loaded): 27.32 kg / 60.23 lbs
