SWIT BIVO-200 160Wh 14V/28V High Load B-Mount Battery

Swit
Partno: SWT-BIVO-200
Stock status: Ships in 5-8 days
SEK 8014

Description

SWIT BIVO-200 160Wh 14V/28V High Load B-Mount Battery

BIVO-200 is a 14.4V(10.8-16.8V) and 28.8V (22-33.6V) Bi-voltage B-mount battery, for ARRI cameras and various compatible with regular voltage cameras and cinegears. The battery will recognize the ID pin resistor value of the B-mount plate, and then output 14.4V or 28.8V, without any misuse risks.

Key Features

- 14.4V/28.8V Bi-voltage B-mount
- 196Wh high capacity
- 200W constant high load
- 33.6V 100W fast charging
- D-tap 11-16.8V output ×2
- OLED power info display
- Built-in LED torch
- Strong 1.2m drop off proof
- Multiple circuit protections

Included items

  • Included items:
    - BIVO-200 196Wh Bi-voltage B-mount Battery Pack

Specification

  • Specification:
    Voltage:   28.8V (21.6-33.6V) & 14.4V (10.8-16.8V)
    Capacity:   196Wh
    Constant load:   (28.8V) 200W, 8A/(14.4V) 200W, 16A
    Charging:   33.6V 100W fast charging
    Mount Type:   B-mount, D-tap ×2
    14.4V status:   10.8-16.8V out, 200W load
    28.8V status:   16V regulated out, 50W load
    Charging Temperature:   0-40degr.C
    Discharging Temperature:   -20degr.C-50degr.C (Capacity and Max Load may decrease when operating below 0degr.)
    Net weight:   1.1kg, With package1.15kg
    Dimensions:
    144×100×54mm
