SWIT PB-S98S 98Wh Multi-Sockets Digital Battery, V-Mount

Swit
Partno: SWT-PB-S98S
Stock status: Ships in 5-8 days
SEK 2593

Description

SWIT PB-S98S 98Wh Multi-Sockets Digital Battery, V-Mount

Square shape design for Cine-cameras
PB-S series camera batteries are compact designed, shorter than normal V/Gold mount batteries, and match perfectly with most of the Cine-cameras.

Key Features

- Square shape design for Cine-cameras
- Max 150W, 12A load
- 2× D-tap output sockets (120W/10A in total)
- 1× USB 5V/2A power output sockets
- OLED display accurate remaining run time
- Display power info in both SONY & RED
- Multiple circuit protections

Included items

  • Included items:
    - PB-S98S 98Wh Multi-sockets Digital Battery Pack

Specification

  • Specification:
    Battery plate:   V-mount
    Nominal voltage:   14.4V
    Capacity:   98Wh,6.8Ah
    Max output
    In total:   150W
    Electrodes:   150W, 12A
    USB:10W, 5V/2A
    D-tap:   120W / 10A
    Dimension:   121×95×59mm
    Charging Temperature:   0-40degr.C
    Discharging Temperature:   -20degr.C-50degr.C(Capacity and Max Load may decrease when operating below 0degr.)
    Net weight:   Net 0.809kg; With package0.85kg
    Max charging current:   3A
    D-TAP socket number:   2
    USB socket number:   1
