VL-2X (2-Channel Fully Sequential Quick Charger)
Description
VL-2X
2-Channel Fully Sequential Quick Charger with AC Power Supply Adaptor (36W DC @ 13.8V)
The VL-2X delivers slim, lightweight 2-channel charging with the added advantage of an integrated 36W power supply. The VL-2X is a multi-chemistry charger for both Li-ion and Ni-Cad battery types.
- Sequential 2-channel charging in either position. The VL-2X will charge the first battery connected to either VMount channel, automatically switching to charge the second battery after the first is fully charged.
- Integrated 36W DC power supply provides 36W XLR output for the camera, lighting or ancillary broadcast devices.
- Compact, lightweight charger body (87.4mm in width / 430g in weight)
- Integrated locking support stand
- Internal safety features protect both the battery and charger from serious damage should faulty or misused batteries be placed on charge. The VL-2X will automatically stop charging should any battery reach an over voltage condition.
- System includes 60W AC-Adaptor Power Supply for power
Included items
Specification
- Specification:
Input Voltage: AC 100~240V 50/60Hz.
Power Consumption: MAX 140VA.
Quick Charge Current: 1.9A.
DC Output:
Maximum output in DC operation: DC 15V / 2.4A (Max 36W)
Battery Output: Battery voltage through output/Battery max. discharge current
Operating Temperature: 0°C ~ 40°C.
Dimensions: 87.4(W) x 183.3(H) x 126.6(D) mm.
Weight: 430g approx.
