SWIT BM-U275HDR-8K 27in 4K/8K 12GSDI HDR Studio Monitor

SWIT BM-U275HDR-8K 27in 4K/8K 12GSDI HDR Studio Monitor

23.8-inch 1000nits 4K
UHD panel, 89% REC2020

BM-U245HDR adopts a 23.8-inch 10-bit LCD
panel, UHD 3840×2160 resolution, 1000nits LED
backlight, 1000:1 contrast, 91.9% DCI-P3 and 89% Rec2020 color gamut. The viewing angle is H178degr. / V178degr..?

Key Features

- 23.8-inch LCD Panel, 3840×2160 resolution
- 1000nits high bright LED backlight
- HLG/PQ/S-log3 HDR, Payload ID auto setting
- 12GSDI 4-in 4-out, 8K input ready, HDMI2.0 input
- 12GSDI via SFP Fiber input (Optional)
- ST2110 IP via SFP Fiber input (Optional)
- SFP Fiber 12G input converted to 12GSDI out
- 3DLUT Auto Self-calibration without PC
- Audio/Video 0 latency for lip-sync
- Built-in Multi camera Delog LUTs
- User 3DLUTs upload via USB
- Waveform / Vector / Histogram
- Focus assist / False color / Zebra
- 16-ch audio meters / Lissajous
- IP webserver remote control
- TSL UMD and text TALLY display
- USB firmware upgrade
